Apex Model: TD350HH 60HP
The TD350HH 60HP Apex pump is the largest model in the pumping range. This single impeller design is capable of high head discharge while maintaining high volume output. The portable design of the TD350HH 60HP also features adjustable polyurethane wear parts. Standard impellers are cast alloy with optional stainless steel impellers. This pump features a very durable fiber composite housing with a heavy duty cast aluminum main frame.
| Motor Data | |
|---|---|
| Horsepower | 60 hp |
| Full load amp | 68 |
| RPM | 3600 |
| 3ph/60hz/460v | |
| Insulation Class | H (180C) |
| Thermal Overload Contacts | |
| Opening Temperature | 150C |
| Start | Delta |
| Material | |
| Outer Casing | Composite |
| Discharge | Aluminum - 4" |
| Stator Housing | Aluminum |
| Stainer | Steel/Powder Coated |
| Wear Parts | Polyurethane |
| Impeller | Alloyed Cast-Iron |
| Optional Impeller | 17-4 S.S. |
| Rotor Shaft | 400 Series Stainless Steel |
| Seal Material | |
| Cemented Tungsten Carbide in Stainless Steel Holder | |
| Weight | |
| Total (Less cable) | 625 lbs |
