Apex Model: SD250HH 13HP
The SD250HH 13HP Apex pump is one of the mid-sized models in the pumping range. This dual impeller design makes it suitable for high head dewatering appilcations. The portable design of the SD250HH 13HP also features adjustable polyurethane wear parts. Standard Impellers are cast alloy with optional stainless steel impellers. The SD250HH 13HP has been used in thousands of installations and is our most popular pump that we offer.
| Motor Data | |
|---|---|
| Horsepower | 13 hp |
| Full load amp | 16 |
| RPM | 3600 |
| 3ph/60hz/460v | |
| Insulation Class | H (180C) |
| Thermal Overload Contacts | |
| Opening Temperature | 130C |
| Start | Y |
| Material | |
| Outer Casing | Aluminum |
| Discharge | Aluminum - 4" |
| Stator Housing | Aluminum |
| Stainer | Steel/Powder Coated |
| Wear Parts | Polyurethane |
| Impeller | 17-4 S.S. |
| Rotor Shaft | 400 Series Stainless Steel |
| Seal Material | |
| Cemented Tungsten Carbide in Stainless Steel Holder | |
| Weight | |
| Total (Less cable) | 198 lbs |
