Apex Model: SD240HH 30HP
The SD240HH 30HP Apex pump is one of the larger models in the pumping range. This single impeller design has proven to be very reliable and economical to maintain. The portable design of the SD240HH 30HP also features adjustable polyurethane wear parts. Standard impellers are cast alloy with optional stainless steel impellers. The wide base design makes this a very stable pump when placed on uneven surfaces.
| Motor Data | |
|---|---|
| Horsepower | 30 hp |
| Full load amp | 34 |
| RPM | 3600 |
| 3ph/60hz/460v | |
| Insulation Class | H (180C) |
| Thermal Overload Contacts | |
| Opening Temperature | 130C |
| Start | Y |
| Material | |
| Outer Casing | Aluminum |
| Discharge | Aluminum - 4" |
| Stator Housing | Aluminum |
| Stainer | Steel/Powder Coated |
| Wear Parts | Polyurethane |
| Impeller | Alloyed Cast-Iron |
| Optional Impeller | 17-4 S.S. |
| Rotor Shaft | 400 Series Stainless Steel |
| Seal Material | |
| Cemented Tungsten Carbide in Stainless Steel Holder | |
| Weight | |
| Total (Less cable) | 375 lbs |
