Apex Model: SD120HV 13HP
The SD120HV 13HP Apex pump is one of the mid-sized models in the pumping range. This high volume design is suited for low head applications that require large volume capacity. Small and portable, the SD120HV 13HP also features adjustable polyurethane wear parts. Impeller is 17-4 S.S. alloy.
| Motor Data | |
|---|---|
| Horsepower | 13 hp |
| Full load amp | 16 |
| RPM | 3600 |
| 3ph/60hz/460v | |
| Insulation Class | H (180C) |
| Thermal Overload Contacts | |
| Opening Temperature | 130C |
| Start | Y |
| Material | |
| Outer Casing | Aluminum |
| Discharge | Aluminum - 6" |
| Stator Housing | Aluminum |
| Stainer | Steel/Powder Coated |
| Wear Parts | Polyurethane |
| Impeller | 17-4 S.S. |
| Rotor Shaft | 400 Series Stainless Steel |
| Seal Material | |
| Cemented Tungsten Carbide in Stainless Steel Holder | |
| Weight | |
| Total (Less cable) | 198 lbs |
